Expandable Graphite 9080270



Product Name Natural Flake Graphite
Manufactured by Qingdao Unimate Graphite Co., Ltd.
Specification 9080270

Certificate of Analysis



Certificate No.s Date of Testing Order Q’ty
Batch No.s Q’ty of Testing Record





Items Unit Acceptance Requirements Typical Note
 Chemical Composition
Fixed Carbon % 93.05 100-Ash
Ash  % 6.95 Fired until constant-weight at 950 to 970℃
Volatile matter  % 18.49 270℃±20℃×7min maintaince
Partical Size Analysis
+80 Mesh  % 72
Other Properties
PH  % 6.44
Moisture  % 0.69
Tap Density g/cm3 275



Tested by: (Lab Technician) Checked by: (Lab Manager)
Zhang Shuyan Yu Shenghui
Approved by: (QC Manager) Conclusions:
Liu Yongling Qualified
