| Product Name |
Natural Flake Graphite |
| Manufactured by |
Qingdao Unimate Graphite Co., Ltd. |
| Specification |
SG11 |
Certificate of Analysis
| Certificate No.s |
– |
Date of Testing |
– |
Order Q’ty |
– |
| Batch No.s |
– |
Q’ty of Testing |
– |
Record |
– |
| Items |
Unit |
Acceptance Requirements |
Typical |
Note |
| Chemical Composition |
|
|
|
|
| Fixed Carbon |
% |
≥99.95 |
99.963 |
100 – Ash |
| Ash |
% |
≤0.05 |
0.037 |
Fired until constant-weight at 950 to 970℃ |
| Partical Size Analysis |
|
|
|
|
| D10 |
μm |
6.5~8.0 |
7.579 |
|
| D50 |
μm |
10.5~12.0 |
11.408 |
|
| D90 |
μm |
17.5~18.5 |
18.274 |
|
| Dmax |
μm |
≤35 |
— |
|
| Other Properties |
|
|
|
|
| PH |
– |
5.0~7.5 |
6.35 |
|
| Moisture |
% |
≤0.1 |
0.05 |
|
| Tap Density |
g/cm3 |
17.5~18.5 |
18.274 |
|
| SSA |
m2/g |
10.0~11.5 |
10.339 |
|
| Fe |
ppm |
≤50 |
36 |
|
| Tested by: (Lab Technician) |
Checked by: (Lab Manager) |
| Zhang Shuyan |
Yu Shenghui |
| Approved by: (QC Manager) |
Conclusions: |
| Liu Yongling |
Qualified |
